Description
Nominal size:100mm
Ranges:0-6bar or Vacuum to 5bar
Case material:304 SS case
Window:safety glass
Pressure element:C type for sealed bourdon tube (<100bar) Coiled type(>100bar)
Joints:soldered with tin alloy/silver
Movement:316
Process connection:1/2" BSP 22mm hexagon block or according to buyer's requirements
Dial:Aluminium,white
Accuracy class:1.0
